TH 45" EPP JabberWocky

TH 45-Inch EPP JabberWocky: 3D Bush Aircraft

Designed by Cody Wojcik, the JabberWocky combines the versatility of a high-wing bush aircraft with the control authority and performance of a dedicated 3D model. Its lightweight EPP construction creates a durable airframe suited for sport flying, bush-style operation, and aggressive aerobatics.

The 44-inch wingspan provides excellent visibility and presence without creating an overly heavy aircraft. Optional suspension landing gear and a dedicated float kit allow the JabberWocky to be adapted for rough fields, conventional runways, or water flying.

Key Features

• High-wing design combining bush flying and 3D aerobatic capability
• Lightweight and durable EPP foam construction
• Designed by Cody Wojcik
• Strong control authority for sport and aggressive 3D flying
• Six-servo recommended control setup
• Compatible with optional suspension landing gear
• Compatible with the dedicated JabberWocky float kit

Specifications

• Wingspan: 44 inches
• Estimated Flying Weight: Approximately 20 oz
• Recommended Battery: 3S 850 mAh LiPo with XT30 connector
• Recommended Propeller: 10 x 4.7 Slow Fly
• Construction: Lightweight EPP foam airframe with a fully airfoiled wing.
• Flight Style: Bush, sport, and 3D flying
• Pilot Level: Intermediate to Advanced

Required to Complete

This is an airframe kit. The recommended power system and additional required items are sold separately and listed below. No printed manual is included; a downloadable PDF build manual is available under Build Resources.

Matched Power-System Components

• Motor: CSP 2213 1100KV 60 g brushless motor
• ESC: BOLT 22A ESC with XT30 connector
• Servos: Six CSP-D10M digital metal-gear servos
• Propeller: 10 x 4.7 Slow Fly propeller

Additional Required Items

• Radio System: 6 to 7-channel transmitter and a compatible lightweight receiver
• Battery: 3S 850 mAh LiPo battery with XT30 connector
• Servo Extensions: Two 14 cm servo extensions and two 30 cm servo extensions
• Charger: LiPo-compatible balance charger
• Adhesive: Foam-Tac or a similar foam-safe adhesive, with CA glue used where specified in the manual

Build Resources, Upgrades and Compatible Parts

• View the JabberWocky PDF Build Manual
• Shop JabberWocky Replacement Parts
• View the JabberWocky Suspension Landing Gear Kit R2
• View the JabberWocky Float Kit
• View the Compatible Ultra Halo XX1 LED Lighting Kit
