TH 39" EPP ARES XL JET

Ares XL: 39-Inch EPP Sport Jet

The Ares XL expands the original indoor Ares into a larger outdoor EPP sport jet with the smooth, realistic feel of a much larger aircraft. Developed with Krill Aircraft and Jack Jehle, it delivers precise handling, strong low-speed control, and excellent energy retention for confident turns, fast passes, and aerobatic flight.

Its fully airfoiled wing and reinforced lightweight construction provide stability, durability, and composed performance in moderate wind. Dual aileron servos provide accurate control, while the centrally mounted motor helps protect the propeller during landings.

Key Features

• Developed with Krill Aircraft and Jack Jehle
• Fully airfoiled wing for smooth and predictable handling
• Excellent low-speed control and energy retention
• Stable during fast passes, turns, and aerobatic flight
• Lightweight reinforced EPP construction
• Dual aileron servos for accurate control response
• Center-mounted motor helps protect the propeller during landings
• Compact size with the flying character of a larger aircraft

Specifications

• Wingspan: 1000 mm / 39.4 inches
• Length: 1120 mm / 44.1 inches
• Estimated Flying Weight: 330 to 420 g / 11.6 to 14.8 oz
• Construction: Lightweight reinforced EPP foam with a fully airfoiled wing
• Recommended Battery: 3S 850 to 1500 mAh LiPo
• Pilot Level: Intermediate to Advanced

Required to Complete

This is an airframe kit. The recommended power system and additional required items are sold separately and listed below. No printed manual is included; a downloadable PDF build manual is available under Build Resources below.

Matched Power-System Components

• Vertex VS28-07X 1700KV motor, 58 g
• BOLT 30A ESC
• Four CSP-D10M digital metal-gear servos
• Gemfan 6 x 4.5 three-blade propeller

Recommended Power Setup

• Battery: 3S 850 to 1500 mAh LiPo, 25C or greater
• Propeller: Gemfan 6 x 4.5 three-blade propeller

Additional Required Items

• Radio System: 4-channel or greater transmitter and a compatible lightweight receiver
• Battery: 3S 850 to 1500 mAh LiPo battery
• Charger: LiPo-compatible balance charger
• Adhesives: Foam-Tac and thin CA glue

Build Resources, Upgrades and Compatible Parts

• Download the Ares XL PDF Build Manual
• Visit the Official Ares XL RC Groups Build Discussion
• Shop Compatible 37 to 39 Inch Replacement Parts
• Shop Compatible Upgrade Parts
• Shop the Compatible Ultra Halo XX1 LED Lighting Kit

We recommend Foam-Tac for the main EPP assembly and thin CA glue for installing the carbon-fiber reinforcement.
